Tech Specs

Performance
Driving Features

– Forward & reverse throttle lever
– Adjustable speed control dial
– Automatic electromagnetic braking
– LED front headlight
– Horn function

Maximum Speed

– 8 km/h (4.97 mph)

Climbing Ability

– Up to 8° incline

Range Per Charge

– 15–25 km (10–16 miles)
(Varies by terrain, temperature, and user weight)

Design
Designer

– Metro Mobility

Model

– Max Plus

Materials

– Polymer body panels
– Metal structural frame
– Upholstered seating

Type

– Compact, non-medical mobility scooter
– Designed for single-person use

Structure & Comfort

– Foldable tiller
– Adjustable padded seat
– Flip-up armrests
– Removable front basket

Weight

– Overall: 52 kg
– Seat: 8.7 kg
– Battery: 12.8 kg

Water Resistance

–IPX4

Dimensions (L × W × H)

– 1080 × 510 × 990 mm

Electronics & Connectivity
Electronics & Connectivity
Controller

– Dynamic DR50-A01 (dealer programmable)

Electrical System

– 24V DC motor
– Electromagnetic braking system
– Diagnostic beep codes for quick troubleshooting

Indicators & Controls

– LED headlight
– LED battery gauge
– Key switch power control

Safety Electronics

– Freewheel safety sensor
– Multiple fuse protections
– 15-minute auto sleep mode

Battery
Battery
Battery Type

– Dual 12V sealed lead-acid (20Ah total)

Charging Time

– 8–12 hours

Charging Specifications

– Off-board charger: 24V / 2A
– LED charging indicators
– Built-in overload protection
– Chip fuse safety

Capacity & Usage
Capacity & Usage
Max User Weight

– 136 kg (300 lbs)

Curb Handling

– Recommended maximum curb height: 45 mm

Recommended Use

– Ideal for users with limited walking ability
– Suitable for shopping, daily errands, outdoor paths

Built-In Components List

  • Seat

  • Armrests

  • Basket

  • Battery Box

  • Seat Post

  • Detent Pin (for Seat Post)

  • External Charger

  • Armrest Adjustment Knobs

  • Keys

FAQs

Please read our FAQs page to find out more.

How long does it take to fully charge the Max Sport battery?

With the original 24V off-board charger, a full charge typically requires 8–10 hours. For best long-term performance, charge the battery indoors, keep the charger dry, and avoid interrupting the charging cycle.

What is the maximum weight capacity of the Max Sport mobility scooter?

Max Sport is engineered to safely support riders up to 300 lbs (136 kg).
Real-world performance—such as range, acceleration, and hill climbing—may vary based on rider weight and terrain.

Is the seat height adjustable on the Max Sport?

Yes. The Max Sport seat height can be easily adjusted using the detent pin on the seat post.
Armrests are also width-adjustable for a more comfortable and personalized riding position.

Can the Max Sport be disassembled for transport?

Absolutely. Max Sport features a tool-free modular design.
The seat, seat post, battery, basket, and tiller fold or detach within minutes, allowing the scooter to fit into most standard car trunks.

What is the driving range of the Max Sport on a single charge?

Under typical conditions, Max Sport delivers an estimated 10–16 miles (15–25 km) per charge.
Actual range varies depending on rider weight, temperature, slope, terrain type, and battery condition.

How well does the Max Sport handle slopes?

Max Sport is tested to safely climb inclines up to 8° with riders weighing up to 300 lbs.
For safety, reduce speed when reversing on slopes and avoid driving across uneven surfaces where wheels are at different levels.

How do I know when the Max Sport battery is fully charged?

The off-board charger displays clear LED indicators:

Red — Power on

Orange — Charging

Green — Fully charged
Unplug the charger once the status light turns green.

Does the Max Sport have safety features for everyday use?

Yes. Max Sport includes multiple safety enhancements, such as:

Automatic electromagnetic braking

Rear anti-tip wheels

LED lighting for visibility

Freewheel mode for manual pushing

IPX4 water-resistant electronics

Intelligent error alerts using audible beeps

How do I control speed on the Max Sport?

Speed is managed through two controls:

The Speed Control Knob sets your maximum speed limit.

The Throttle Lever fine-tunes acceleration while driving.
Reverse speed is automatically reduced for controlled maneuvering.

Why won’t my Max Sport scooter drive even though the key is on?

Several common causes include:

  • The freewheel lever is unlocked (switch to locked/drive mode).
  • The charger is still plugged in.
  • The reset button on the battery has popped out (press it in).
  • The battery pack is not fully seated on the connectors.

If the scooter beeps in a repeated pattern, refer to the built-in diagnostic codes for troubleshooting.
